PID Self-Tuning Temperature Control Mode UV Weathering Test Chamber
For Nonmetallic Materials
UV aging testing chamber is applicable for the sunlight resistant test of nonmetallic
materials and aging test of artificial light sources. A variety of
industrial products can make the reliability test, and this product
can simulate the product in the sun, rain, humidity and dew
conditions, including damage caused by bleaching, color, brightness
down, powder, crack, blur, brittle, intensity decreased and
oxidation.
Applications
1. Simulate the sun, rain spray and condensation resulting damage
to test the materials by exposure to sunlight with moisture and
temperature.
2. To get the results of damage after several days or weeks which
is equal to expose to outside for a few months. The damages include
fading, discoloration, brightness down, powder, crack, blur,
brittle, strength decreases and oxidation.
3. Provide reference with testing data for improvement of existing
materials, or to assess the impact of changes in product durability
and other aspects.
Test Criteria
ISO 4892-3,ASTM G154....
The main technical parameters:
| Item | Specification |
| Chamber dimension (W*D*H) | 1300*500*1460mm |
| Chamber material | SUS#304 stainless steel |
| Temperature range | RT to 70℃ |
| Temperature fluctuation | ≤±1.0℃ |
| Temperature uniformity | 3℃ |
| Humidity range: | ≥75%RH |
| Controller | Programmable controller, LCD touch screen |
| Control mode | Balance temperature humidity control (BTHC) |
| Test cycle setting | Exposure, condensation and water spray test cycle is programmable |
| Water spray cycle | Spray 18mins in every 120mins / spray 12mins in every 60mins |
| Water usage | 8L/day |
| Distance from sample to lamp | 55±2mm |
| Centre distance between lamps | 65~70mm |
| Irradiance range | 0.45~0.90W/m2 |
| UV lamps | Imported Atlas UV-A: 315-400nm (8pcs, 1600h lifetime) |
| Lamp power | 40W/Piece |
| Specimen Size | 75×290mm (24pcs) / 75x150mm (48pcs), maximum thickness 5mm |
| Testing time | 0~999H, adjustable |
| Protection system | Overload short circuit protection Over temperature protection Water lacking protection Earth leakage protection Auto shut off protection |
